Load Balancing

Load Balancing Definition: Load balancing is the process of distributing network traffic across multiple servers. This ensures no single server bears too much demand. By spreading the work evenly, load balancing improves application responsiveness. It also increases availability of applications and websites for users. Modern applications cannot run without load balancers. Over time, load balancers have added additional capabilities including security and application acceleration

CompTIA Network+ Certification

About Load Balancers

As an organization meets demand for its applications, the load balancer decides which servers can handle that traffic. This maintains a good user experience.

Load balancers manage the flow of information between the server and an endpoint device (PC, laptop, tablet or smartphone). The server could be on-premises, in a data center or the public cloud. The server can also be physical or virtualized. The load balancer helps servers move data efficiently, optimizes the use of application delivery resources and prevents server overloads. Load balancers conduct continuous health checks on servers to ensure they can handle requests. If necessary, the load balancer removes unhealthy servers from the pool until they are restored. Some load balancers even trigger the creation of new virtualized application servers to cope with increased demand.

Traditionally, load balancers consist of a hardware appliance. Yet they are increasingly becoming software-defined. This is why load balancers are an essential part of an organization’s digital strategy.

Download this report to learn how the NSX Advanced Load Balancer (Avi Networks) distributed over 1 million SSL transactions per second with the help of Intel’s high-performance CPUs

History of Load Balancing

Load balancing got its start in the 1990s as hardware appliances distributing traffic across a network. Organizations wanted to improve accessibility of applications running on servers. Eventually, load balancing took on more responsibilities with the advent of Application Delivery Controllers (ADCs). They provide security along with seamless access to applications at peak times.

ADCs fall into three categories: hardware appliances, virtual appliances (essentially the software extracted from legacy hardware) and software-native load balancers. As computing moves to the cloud, software ADCs perform similar tasks to hardware. They also come with added functionality and flexibility. They let an organization quickly and securely scale up its application services based on demand in the cloud. Modern ADCs allow organizations to consolidate network-based services. Those services include SSL/TLS offload, caching, compression, intrusion detection and web application firewalls (WAF). This creates even shorter delivery times and greater scalability.

Load Balancing and SSL

Secure Sockets Layer (SSL) is the standard security technology for establishing an encrypted link between a web server and a browser. SSL traffic is often decrypted at the load balancer. When a load balancer decrypts traffic before passing the request on, it is called SSL termination. The load balancer saves the web servers from having to expend the extra CPU cycles required for decryption. This improves application performance.

However, SSL termination comes with a security concern. The traffic between the load balancers and the web servers is no longer encrypted. This can expose the application to possible attack. However, the risk is lessened when the load balancer is within the same data center as the web servers.

Another solution is the SSL pass-through. The load balancer merely passes an encrypted request to the web server. Then the web server does the decryption. This uses more CPU power on the web server. But organizations that require extra security may find the extra overhead worthwhile.

Load Balancing and Security

Load Balancing plays an important security role as computing moves evermore to the cloud. The off-loading function of a load balancer defends an organization against distributed denial-of-service (DDoS) attacks. It does this by shifting attack traffic from the corporate server to a public cloud provider. DDoS attacks represent a large portion of cybercrime as their number and size continues to rise. Hardware defense, such as a perimeter firewall, can be costly and require significant maintenance. Software load balancers with cloud offload provide efficient and cost-effective protection.

CompTIA Network+ Certification

Load Balancing Algorithms

There is a variety of load balancing methods, which use different algorithms best suited for a particular situation.

  • Least Connection Method — directs traffic to the server with the fewest active connections. Most useful when there are a large number of persistent connections in the traffic unevenly distributed between the servers.
  • Least Response Time Method — directs traffic to the server with the fewest active connections and the lowest average response time.
  • Round Robin Method — rotates servers by directing traffic to the first available server and then moves that server to the bottom of the queue. Most useful when servers are of equal specification and there are not many persistent connections.
  • IP Hash — the IP address of the client determines which server receives the request.



Load balancing has become a necessity as applications become more complex, user demand grows and traffic volume increases. Load balancers allow organizations to build flexible networks that can meet new challenges without compromising security, service or performance.

Load Balancing Benefits

Load balancing can do more than just act as a network traffic cop. Software load balancers provide benefits like predictive analytics that determine traffic bottlenecks before they happen. As a result, the software load balancer gives an organization actionable insight. These are key to automation and can help drive business decisions.

In the seven-layer Open System Interconnection (OSI) model, network firewalls are at levels one to three (L1-Physical Wiring, L2-Data Link and L3-Network). Meanwhile, load balancing happens between layers four to seven (L4-Transport, L5-Session, L6-Presentation and L7-Application).

Load balancers have different capabilities, which include:

  • L4 — directs traffic based on data from network and transport layer protocols, such as IP address and TCP port.
  • L7 — adds content switching to load balancing. This allows routing decisions based on attributes like HTTP header, uniform resource identifier, SSL session ID and HTML form data.
  • GSLB — Global Server Load Balancing extends L4 and L7 capabilities to servers in different geographic locations.

More enterprises are seeking to deploy cloud-native applications in data centers and public clouds. This is leading to significant changes in the capability of load balancers. In turn, this creates both challenges and opportunities for infrastructure and operations leaders.
